ECONOMI SL11 is a high cost effective LED street light series, simplified structure with fins style radiator to achieve fast cooling, downward surface is flat by tempered glass cover which is a trusted roadway lighting option.
ECONOMI SL11 is a high cost effective LED street light series, simplified structure with fins style radiator to achieve fast cooling, downward surface is flat by tempered glass cover which is a trusted roadway lighting option.
Specification
・4 sizes from 10W to 240W
・Fins style radiator
・Tempered glass cover
・High efficiency up to 170lm/w
・Multiple optic lenses
・Easy installation
・Up to C5-M anti-corrosion
・Smart-ready, Zhaga on both top and downward
Details
| Product model | EL-SL11 |
| Size | MINI/S/M/L |
| Nominal power | 10-50W/50-100W/100-150W/150-240W |
| LED type | 3030/5050 |
| CCT | 1800-6500K |
| CRI | Ra>70 (Ra>80 optional) |
| Max luminous efficiency | 170lm/w |
| Max luminous flux | 40,800lm |
| Optics | Type II/III/IV/V |
| Driver function | On-Off /0-10V/Timer Dim./DALI2/D4i |
| Insulation | Class I/II |
| Glass cover | Yes |
| Housing material | Die-cast aluminum |
| IP Rating | IP66 |
| IK Rating | IK08 |
| Colour of finish | Grey |
| Operation Temperature | -40°C to +50°C |
| Mounting | Side entry on pole |
| Pole diameter to fit | Ø48(MINI), Ø60(S/M/L) |
| Extension interface | NEMA/ZHAGA |
| Certificate | CB/ENEC/CE/RoHS |
