DIAMOND PRO is a premium version of the Diamond series, integrated with a tool-free opening function. It achieves an ultra-lightweight design while maintaining excellent lighting performance. DIAMOND PRO stands out with its unique appearance, well-engineered structure, and a variety of user-friendly details.
Specification
・Modern style park light design
・Power from 10W to 100W
・Different mounting options
・The best sense of urban integration
・Tempered glass cover
・Tool-free open
・High efficiency up to 180lm/w(Version B)
・Multiple optic lenses T1~T5
・Smart-ready, Zhaga on both top and downward
Details
| Product model | EL-GL08 |
| Type | A/B/C |
| Nominal power | 10-100W |
| LED type | 5050 |
| CCT | 1800-6500K |
| CRI | Ra>70 (Ra>80 optional) |
| Max luminous efficiency | 180lm/w |
| Max luminous flux | 18,000lm |
| Optics | Type II/III/IV/V |
| Driver function | On-Off /0-10V/Timer Dim./DALI2/D4i |
| Insulation | Class I/II |
| Glass cover | Yes |
| Housing material | Die-cast aluminum |
| IP Rating | IP66 |
| IK Rating | IK09 |
| Colour of finish | Grey |
| Operation Temperature | -40°C to +50°C |
| Mounting | Post top/Side entry/Suspended |
| Pole diameter to fit | Ø60 |
| Extension interface | NEMA/ZHAGA |
| Certificate | CB/ENEC/CE/RoHS(Pending) |
Download
Embrace a green future
As a practitioner of environmentally friendly lighting, we will continue to innovate, continuously optimize product performance, improve lighting efficiency, reduce energy consumption, and contribute to building a green, low-carbon, and sustainable urban environment.
